HIGH PRESSURE WATER JETTING SYSTEMS

Main Specifications

  1.  Code 1.132.875
  2.  Type JMB-H 500/18 TG2
  3.  Working pressure (bar) 30 - 500
  4.  Flow rate (l/h) 1080
  5.  Max.water temperature. 30 - 120 °C
  6.  Motor rating 26.0 kW (diesel)
  7.  Battery 12 V
  8.  Dimensions L x W x H 3825 x 1765x 2240mm
  9.  Weight 1070 kg
  10.  Water tank 620L
  11.  Fuel tank 104 L
  12.  Burner capacity 110 kW




Unit Feature Include

  1.  Industrial 2,3 or 4-cylinder diesel engine with preheating of water in the tank via heat exchanger. This saves up 15% fuel for the burner.
  2.  Motor control system with several indicator lights.
  3.  Radial high pressure pump with 3 ceramic plungers and stainless steel valve.
  4.  Extra function for overheated water (100 C at the nozzle).
  5.  Boiler with independent motor filled and fuel valve with electronic ignition.
  6.  12 V operating voltage.
  7.  Presssure Guage
  8.  Hour Counter
  9.  Temperature adjustment and thermostat.
  10.  Fuel meter (not on built-in configuration).
  11.  Data Management
  12.  Pressure relief up to 10 bar with sealed gun.
  13.  Sleepless steel water tank 620L
  14.  Stainless Steel fuel tank 104L
  15.  Trailer Version: double-axle trailer fitted with swivel wheel and brake.

Standard Accessories

  1.  1 set of tee for connecting two high pressure hoses.
  2.  2 pcs of integrated high pressure hose reels with 50m 3/8in high pressure hose.
  3.  1 pc of integrated low pressure hose reels with 50m 3/4in low pressure hose.
  4.  Single stainless steel lance with high pressure nozzle and rotating quick coupling.
  5.  High pressure gun with swivel.
